Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications

Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications
Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications
Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications

Grote Afbeelding :  Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications

Productdetails:
Plaats van herkomst: China
Merknaam: ZIITEK
Certificering: UL and RoHs
Modelnummer: TIF100-30-06S
Document: TIF100-30-06S_Data Sheet.pdf
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 1000 STUKS
Prijs: Onderhandelbaar
Verpakking Details: 1000 STKS/ZAK
Levertijd: 3-5 werkdagen
Betalingscondities: T/T
Levering vermogen: 100000 stks/dag
Contact

Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications

beschrijving
Producten Naam: Thermisch geleidend siliconenmateriaal met een thermische geleidbaarheid van 3,0 W/mK voor toepassin Thermische geleidbaarheid: 3.0W/m-k
Sollicitatie: Elektrisch gereedschap Warmteafvoertoepassingen Trefwoorden: Thermisch Geleidend Stootkussen
Hardheid: 65/45 Kust 00 Soortelijk gewicht: 30,0 g/cm3
Aanbevolen bedrijfstemperatuur (%22C): -40 aan 200℃ Doorslagspanning (V/mm): ≥5500 VAC
Kleur: wit

Thermal Conductive Pad Silicone Material with 3.0W/mK Thermal Conductivity for Power Tools Heat Dissipation Applications


Company Profile

Dongguan Ziitek Electronic Material and Technology Ltd. (ZIITEK) has been deeply involved in the field of heat conducting materials for many years, and is a high-tech enterprise integrating R&D, production and sales. Headquartered in Dongguan, with four production bases in Kunshan, Taiwan Province and Viet Nam, the global delivery capacity is stable and reliable. Mainly engaged in thermal conductive silica pads, thermal conductive graphite sheets, thermal conductive insulation materials, PCM phase change materials, thermal conductive plastics, thermal conductive silicone grease/paste, thermal conductive gel, thermal conductive epoxy potting glue, thermal conductive silicone adhesive, silicone foam, and silicon-free thermal pads. The core explosive heating plate is widely recognized by the market. Our products have passed ISO9001 and IATF16949 certification, and meet RoHS/UL standards, and are widely used in new energy, 5G, data center, automotive electronics and other fields.


Products description

TIF®100-30-06S Series is awell-balanced,general-purpose thermal pad.It offers high thermal conductivity and moderate hardness. This balanced design provides both excellent suface conformity and superior ease of use, making it capable of effectively transferring heat and providing basic physical protection for a wide range of electronic components. It is an ideal choice for addressing medium to high power heat dissipation needs, achieving the best balance between cost and performance.

Features

>  Good thermal conductive: 6.5 W/mK
>  Moldability for complex parts
>  Soft and compressible for low stress applications
>  Naturally tacky needing no further adhesive coating
>  Available in varies thicknesses

Applications

>  Power tools
>  Network communication products
>  Electric vehicle batteries
>  Computer CPU/GPU Cooling
>  New energy vehicle power systems

Typical Properties of TIF®100-30-06S Series
Property Value Test method
Color White Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Density(g/cm³) 3.0 ASTM D792
Thickness Range(inch/mm) 0.010~0.020 0.030~0.200 ASTM D374
(0.25~0.50) (0.75~5.0)
Hardness (Shroe 00) 65 45 ASTM 2240
Recommended Operating Temperature -40 to 200℃ ******
Breakdown Voltage(V/mm) ≥5500 ASTM D149
Dielectric Constant@ 1MHz 5.2 ASTM D150
Volume Resistivity ＞1.0X1012 Ohm-meter ASTM D257
Flame rating V-0 UL 94 (E331100)
Thermal conductivity 3.0 W/m-K ASTM D5470
3.0 W/m-K ISO22007

Product Specifications

Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"X16" (406 mmX406 mm)

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF® series is available in customshapes and various forms.
For other thicknesses or more information,please contact us.
