Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

China Dongguan Ziitek Electronic Materials & Technology Ltd. certificaten
China Dongguan Ziitek Electronic Materials & Technology Ltd. certificaten
Het thermische Geleidende Stootkussen ziet eruit en zeer goed werkt. Wij hebben geen behoefte nu aan ander Thermisch Geleidend Stootkussen!

—— Peter Goolsby

Ik had met Ziitek 2 jaar samengewerkt, verstrekten zij hoogte - adviseren de kwaliteits thermische geleidende materialen, en de levering op tijd, hun materialen van de faseverandering

—— Antonello Sau

Goede kwaliteit, de Goede dienst. Uw team geeft ons altijd hulp en het oplossen, hoop wij de hele tijd goede partner zullen zijn!

—— Chris Rogers

Ik ben online Chatten Nu

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Grote Afbeelding :  Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Productdetails:
Plaats van herkomst: China
Merknaam: Ziitek
Certificering: RoHs
Modelnummer: TIG780-50HP
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 1 kg
Prijs: 0.1-10 USD/KG
Verpakking Details: 1kg/can
Levertijd: 3-5 werkdagen
Levering vermogen: 100 kg/dag
Gedetailleerde productomschrijving
Naam van producten: Goede thermische geleidbaarheid thermische vet thermische pasta voor elektronische componenten IC, C kleur: grijs
Constructie & Samenstelling: Metaaloxide/siliconenolie Dikte: 2,3g/cm³
Thermische geleidbaarheid: 5,0 W/mK Thermische impedantie ((%22C-in²/W) @30 psi): 0,015
Trefwoorden: Thermische pasta Aanbevolen bedieningstemperatuur: -40 ~ 200 ℃

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS



TIG®780-56 Series is an environmentally friendly silicone based thermal paste designed to efficiently solve overheating problems in electronic devices and improve long-term reliability, TIG®780-50HP is a paste like material that can fully wet the surfaces of electronic components and heat sinks. It acts to fill the gaps between electronic components and heat sinks, eliminate air, and significantly improve heat dissipation eficiency (better than traditional thermal pads or ordinary silicone grease), thereby forming an extremely low thermal resistance interface and achieving excellent thermal conductivity efficiency.



Features



> High thermal conductivity
> Excellent low thermal resistance
> Good electrical insulation
> Excellent long-term stability
> Non toxic, environmentally friendly,and safe, meeting RoHS requirements


Applications lnclude


> Al server
> Industrial equipment
> Medical electronic devices
> LED TV,LED lighting fixtures
> Automotive Electronics (New Energy and Intelligence)
> High end consumer electronics and portable devices



Typical Properties of TIG®780-50HP Series
Property Value Test Method
Color Gray Visual
Construction &Compostion Metal oxide / Silicone oil Ziitek Test Method
Density 2.30 g/cm³ ASTM D792
Thermal Conductivity 5.0W/mK ASTM D5470
Bond line Thickness (mm) 0.008 ASTM D374
Thermal Impedance (℃·in²/W) @30 psi 0.015 ASTM D5470
Thermal Impedance (℃·in²/W) @50 psi 0.012 ASTM D5470
Recommended Operating Temp -40℃ to 200℃ *****
Viscosity(mPa.s) 200000 GB/T 10247



Packaging Specifications


Packaging specifications: 0.5kg,1kg,2kg;

If you have any other specification requirements, please contact our company.
